LTMG 7.5ton Crawler Excavator
1. The whole machine can be equipped with quick-change pipeline, affiliated bidirectional pipeline, affiliated unidirectional pipeline and affiliated rotary pipeline, which expands the function of the whole machine.
2. Greatly improve the reliability, comfort and safety of the whole machine.
Model :
LTE75Operating Weight :
7500kgBucket Capacity :
0.28m³ODM/OEM :
SUPPORT
7.5 Ton Crawler Excavator Product Characteristic
LTMG LTE75 is with 7500kg loading capacity and 0.28cbm bucket, equipped with Kubota V2607 42.4KW and the same hydraulic parts as LONGKING. The excellent design has excellent working efficiency and excellent cost performance.
1. Simple structure, small and flexible, convenient transportation, can be operated in a small field, especially suitable for orchard such as kiwi, vineyard, orange, navel orange value, ditching, fertilization, weeding.
2. Equipped with standard bulldozers, it effortlessly levels sites, backfills earth, and enhances machine stability. This feature further extends its utility across a wide range of construction and agricultural projects, ensuring maximum productivity and efficiency.
7.5 ton Crawler Excavator Product Parameter
| Performance Parameters | Unit | LTE75 |
| Operating Weight | Kg | 7500 |
| Engine Model | Kubota V2607 | |
| Rated Power | Kw | 42.4KW/2000rpm |
| Bucket Capacity | m³ | 0.28 |
| Max Digging Force | Kn | 56 |
| Swing Speed | rpm | 0-11 |
| Traveling Speed | km/h | 2.8 |
| Gradeability | ° | 70(35°) |
| Operating Range | ||
| Max. Digging Radius | mm | 6182 |
| Max. Digging Depth | mm | 3898 |
| Max. Digging Height | mm | 7023 |
| Max. Dumping Height | mm | 5195 |
| Max. Dozer Cutting Distance | mm | 332 |
| Max. Dozer Lifting Distance | mm | 385 |
| Tail Swing Radius Distance | mm | 1730 |
| Overall Dimensions | ||
| Overall Length | mm | 6054 |
| Overall Width | mm | 2216 |
| Overall Height | mm | 2672 |
| Mini.Ground Clearance | mm | 375 |
| Track Width | mm | 450 |
| Undercarriage width | mm | 2195 |
| Undercarriage ground clearance | mm | 375 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
FAQ
1. What payment terms can we accept?
T/T; L/C; D/P
2. What Certificates do we have?
All products meet with the ISO9001 Quality System and have acquired CE certificate. EPA approval will be available if needed.
3.How about our delivery time?
It usually will take 30 days-45 days after receiving your deposit.
4. Can we provide OEM service?
LTMG industrial can provide customized products according to customers' requirements,both OEM and ODM are acceptable.
