300kg small crawler skid steer loader, suitable for indoor and outdoor site engineering operations.
Model :
LTS23Load Capacity :
300kgOperating Weight :
980kgBucket Capacity :
0.15m³ODM/OEM :
SUPPORT
Mini Crawler Skid Steer Loader Product characteristics
1. Standing type, 300kg loading capacity. The total size is small, suitable for small engineering site operation.
2. Imported Italian hydraulic multiway valve, pump, motor.
3. Equipped with imported Briggs & Stratton 23 HP gasoline engine, which meets EPA and European Level 5 emission standards.
4. Colors can be customized
5. It can be installed a variety of skid steer loader accessories
Mini Crawler Skid Steer Loader Product parameter
| Model | LTS23 |
| Type of engine | Imported Bailitong |
| Rated power | 16.9KW |
| Rated speed | 3600rpm |
| Number of cylinders | 2 |
| Air inlet mode | nature |
| Displacement | 0.479L |
| Emission standard | EU5 |
| Rated load | 300Kg |
| Max Load | 400Kg |
| Max lifting Force | 550Kg |
| Bucket Capacity | 0.15m³ |
| Driving speed | 0-6km/h |
| The sum of three items | 9 |
| system pressure bar | 17-21bar |
| Fuel tank capacity | 25L |
| Operating weight | 980Kg |
| Maximum operating height(H) | 2450 mm |
| Height to bucket pin | 1870 mm |
| overall height(C) | 1350 mm |
| Max height on bucket level state | 1810 mm |
| Total length without bucket(E) | 1680 mm |
| Total length（with bucket）(F) | 2206 mm |
| Max height Unloading Angle | 34° |
| Dumping height(A) | 1510 mm |
| Dumping distance | 450 mm |
| Bucket overturning angle on the ground | 27° |
| Max Bucket swing angle | 114 ° |
| Wheel base | 850 mm |
| Ground clearance | 150 mm |
| Tail length | 280 mm |
| overall width(I) | 1150 mm |
| Bucket width(U) | 1200 mm |
With technological innovation, our product configuration and parameters will continue to change without notice
If there is any doubt, the specific confirmation of our international trade sales shall prevail
FAQ about Mini Crawler Skid Steer Loader
1.Why choose us?
As a manufacturer, LTMG Industries is committed to providing not only high quality and high performance skid steer loaders at competitive prices, but also prompt delivery and comprehensive 7/24 after-sales service.
2.What is the product range of our factory?
LTMG Industry is a large machinery manufacturer specializing in the supply of loaders, forklifts, excavators and related accessories. We can also customize non-standard products according to customers' requirements.
3.What payment terms can we accept?
Normally, a 30% deposit is required in advance and 70% of the balance should be settled before shipment. A 100% irrevocable letter of credit with payment on sight on terms we agree to is also acceptable.
4.What Certificates do we have?
All products meet the requirements of CE & ISO9001 quality system and have obtained CE certificate. We also have EPA and Euro V certificates.
5.How about our delivery time?
It usually takes 15 to 30 days after receiving your deposit. Regarding standard products, we always have them in stock for immediate delivery. However, custom products will take more time, depending on your order requirements.
